TC4 Spherical Titanium Alloy Powder Ti6Al4V Good Quality High Purity Hot Sale 3D Printing Powder Advanced Material

Overview Of 3D Printing Ti6Al4V Powder TC4 Powder

Ti6Al4V is a type of α+β Titanium alloy known for its great mechanical properties, good biocompatibility, and corrosion resistance. The powder morphology enables the material to be manufactured layer by layer through 3D printing techniques such as laser powder bed fusion (LPBF) and electron beam melting (EBM), enabling rapid prototyping of complex structural components.

(3D Printing Ti6Al4V Powder TC4 Powder)

 3D Printing Ti6Al4V Powder TC4 Powder

Features of 3D Printing Ti6Al4V Powder TC4 Powder

• Excellent Mechanical Properties4: After 3D printing, it shows high strength, toughness and good wear resistance. The printed parts can withstand high mechanical loads and impacts, with tensile strength reaching 1200 – 1300MPa in the printed state. This makes them suitable for applications with high material performance requirements, such as aerospace and automotive manufacturing.
• Good Corrosion Resistance: TC4 powder contains elements such as titanium, aluminum and vanadium, which can form a dense and stable passive film on the surface. This gives it excellent corrosion resistance in various environments, including salt water and chemical media, making it applicable to the chemical and marine fields.
• Low Density and High Specific Strength4: It has a relatively low density, about 4.43g/cm³, much lower than that of common metals like steel. However, it has high strength, resulting in a high specific strength, which is conducive to reducing the weight of components and improving the efficiency and performance of equipment, which is significant in the aerospace field.
• Good Biocompatibility4: It shows excellent biocompatibility and is less likely to cause immune rejection and other reactions in the human body. Therefore, it is widely used in the medical field to manufacture artificial joints, orthopedic implants and other medical devices, helping to accelerate the patient’s recovery process.
• Good Processability: It has good fluidity, loose packing density and tap density. The powder particles are spherical or nearly spherical with a uniform particle size distribution, usually in the range of 15 – 53μm1. This makes it easy to spread evenly during 3D printing, ensuring the accuracy and surface quality of printed parts.

Parameter table of 3D Printing Ti6Al4V Powder TC4 Powder

Ti6Al4V Powder TC4 Powder Properties
Other Names	Ti6Al4V Powder, TC4 Powder
CAS No.	N/A
Compound Formula	TA0,TA1,TC4,TC4 ELI,TC11,TC17,TC18,TC21,TA7,TA12,TA15,TA17,TA19, Ti40,Ti60,TiAl(Ti36Al,Ti48Al2Cr2Nb),TiNi,TiNb,ZrTi
Molecular Weight	N/A
Appearance	Grey powder
Melting Point	N/A
Solubility in water	N/A
Density	N/A
Purity	99%
Particle Size	0-20μm, 15-45μm, 15-53μm, 53-105μm, 53-150μm, 105-250μm
Boling point	N/A
Specific Heat	N/A
Thermal Conductivity	N/A
Thermal Expansion	N/A
Young’s Modulus	N/A
Exact Mass	N/A
Monoisotopic Mass	N/A
Ti6Al4V Powder TC4 Powder Health & Safety Information
Safety Warning	N/A
Hazard Statements	N/A
Flashing point	N/A
Hazard Codes	N/A
Risk Codes	N/A
Safety Statements	N/A
RTECS Number	N/A
Transport Information	N/A
WGK Germany	N/A

Applications Of 3D Printing Ti6Al4V Powder TC4 Powder

Ti-6Al-4V titanium alloy powder for 3D printing is a widely used titanium alloy powder in multiple fields. The following are its main application areas:

Aerospace: Due to the high strength, low density, and good corrosion resistance of titanium alloys, Ti6Al4V powder is widely used in the aerospace field. It can manufacture engine components, structural components, fasteners, and other components that require high strength, lightweight, and corrosion resistance for aircraft and rockets. Through 3D printing technology, high-precision manufacturing of complex geometric shapes can be achieved, improving the performance and reliability of components.

Medical devices: Ti6Al4V powder is widely used due to its biocompatibility and corrosion resistance. It can be used to manufacture medical devices such as artificial joints, dental implants, surgical instruments, etc. Through 3D printing technology, customized and personalized medical device manufacturing can be achieved, improving patients’ treatment effectiveness and quality of life.

Automotive industry: In the automotive sector, Ti6Al4V powder is mainly used to manufacture high-performance automotive exhaust systems, turbochargers, and other components. The lightweight and high strength of titanium alloy can improve automobile fuel economy and performance. In addition, titanium alloys have good corrosion and high-temperature resistance, making them suitable for harsh working environments in automotive engines.



Applications of 3D Printing Ti6Al4V Powder TC4 Powder



Other fields: Besides aerospace, medical equipment, and automotive industries, Ti6Al4V powder can be applied in other fields, such as petrochemicals, marine engineering, sports goods, etc. In petrochemicals, titanium alloys can manufacture corrosion-resistant pipelines, valves, reactors, and other equipment. In marine engineering, titanium alloys can manufacture components such as evaporators for seawater desalination equipment, pipelines, and valves for offshore oil and gas extraction platforms. In sports equipment, titanium alloy can manufacture high-performance products such as golf clubs and bicycle frames.



 Production Method of 3D Printing Ti6Al4V Powder TC4 Powder

Electrode Induction Melting Inert Gas Atomization (EIGA)

1. Raw Material Preparation: High-purity titanium, aluminum, vanadium and other raw materials are precisely weighed according to the composition ratio of Ti6Al4V to ensure accurate chemical composition.
2. Melting: The raw materials are put into an induction melting furnace and heated to 1600 – 1800°C in an inert gas atmosphere, such as argon until they are completely melted to form a homogeneous molten metal liquid.
3. Atomization: The molten metal flows out of the crucible through a nozzle at a certain speed. Meanwhile, high-pressure argon or nitrogen is sprayed onto the molten metal stream at a high speed. The strong shearing force of the gas breaks the molten metal into tiny droplets.
4. Solidification and Collection: The droplets solidify rapidly during the falling process to form a spherical metal powder, which is collected at the bottom of the atomization chamber.
   Plasma Rotating Electrode Process (PREP)
5. Electrode Preparation: A Ti6Al4V alloy rod is machined into an electrode with a specific diameter and length. The electrode’s surface should be smooth and free of defects.
6. Rotation and Melting: The electrode is placed in a vacuum or inert gas environment and rotates at a high speed of 10,000 – 20,000 revolutions per minute. A plasma arc is used to heat the end face of the electrode to make it uniformly melted.
7. Droplet Formation and Solidification: The centrifugal force generated by high-speed rotation causes the molten metal at the end of the electrode to be thrown out in the form of droplets. The droplets solidify instantaneously into spherical metal powder in the air
   Plasma Atomization (PA)
8. Raw Material Feeding: Ti6Al4V alloy materials are fed into the plasma torch through a feeding device.
9. Melting and Atomization: In the plasma torch, a high-temperature plasma arc with a temperature of up to 10,000°C or more is generated. The raw materials are quickly melted or vaporized in the plasma arc and atomized into fine droplets by the high-velocity plasma jet.
10. Cooling and Collection: The droplets cool and solidify rapidly in an inert gas atmosphere such as argon and are collected in the atomization tower system.

Company Profile

RBOSCHCO is a trusted global chemical material supplier & manufacturer with over 12-year-experience in providing super high-quality chemicals and nanomaterials, including boride powder, nitride powder, graphite powder, sulfide powder, 3D printing powder, etc.The company has a professional technical department and Quality Supervision Department, a well-equipped laboratory, and equipped with advanced testing equipment and after-sales customer service center.If you are looking for high-quality 3D Printing Ti6Al4V Powder TC4 Powder, please feel free to contact us or click on the needed products to send an inquiry.

 Storage Condition of 3D Printing Ti6Al4V Powder TC4 Powder

Controlled Humidity: The powder should be stored in an environment with low humidity. Generally, the relative humidity should be controlled below 30%. High humidity can lead the powder to absorb moisture, which may lead to oxidation and agglomeration and affect the fluidity and formability of the powder during 3D printing.

Reduced Temperature Level: The storage space temperature level ought to be relatively low, ideally between 15 ° C and 25 ° C. An Excessive temperature level can quicken the powder’s oxidation action and influence its efficiency. In addition, sudden temperature modifications must be avoided to prevent condensation on the powder surface.

Inert Gas Protection: Ti6Al4V powder is usually stored in a sealed container filled with an inert gas such as argon or nitrogen. This can isolate the powder from oxygen in the air and reduce the risk of oxidation.

Dust-free and Clean Environment: The storage area should be clean and free of dust and other impurities to prevent foreign matter from mixing into the powder and affecting the quality of the printed parts.

1) Store in a dry environment at room temperature.

2) Avoid damp and high temperature.

3) Use immediately after opening the inner packing bag.

Payment Term

L/C, T/T, Western Union, Paypal, Credit Card etc.



 Shipment Term

By sea, by air, by express, as customers request.

5 FAQs of 3D Printing Ti6Al4V Powder TC4 Powder

Q1

What 3D printing technologies are suitable for Ti6Al4V powder?

Answer: Ti6Al4V powder is suitable for various 3D printing technologies, especially laser powder bed fusion (LPBF), electron beam melting (EBM), and directed energy deposition (DED). These technologies can melt powder layer by layer and construct complex titanium alloy components.



Q2

How to optimize the 3D printing parameters of Ti6Al4V powder?

Answer: Optimizing the 3D printing parameters of Ti6Al4V powder is a complex process that requires consideration of multiple factors, such as laser power, scanning speed, powder layer thickness, atmosphere control, etc. Usually, experiments and tests are required to find the optimal combination of printing parameters. In addition, professional 3D printing software and simulation tools can also be used to assist in the optimization process.



Q3

Do the printed Ti6Al4V components need to undergo heat treatment?

Answer: Usually, the printed Ti6Al4V components need heat treatment. Heat treatment can improve the mechanical properties of components, eliminate internal stresses generated during the printing process, and optimize their microstructure. The specific heat treatment process should be determined based on the purpose and performance requirements of the components.



Q4

What are the precautions for storing and using Ti6Al4V powder?

Answer: When storing and using Ti6Al4V powder, it should be ensured that it is in a dry and clean environment to avoid moisture and contamination. Powder should be kept away from sources of ignition and flammable materials, and appropriate safety measures should be taken, such as wearing protective gloves and respirators, to avoid inhalation and skin contact. Regular inspection of the quality and purity of the powder is also necessary to ensure the stability of the printing process and the quality of the components.



Q5

What are the advantages of Ti6Al4V powder compared to other titanium alloy powders?

Answer: Ti6Al4V powder is a widely used titanium alloy powder that performs excellently in strength, corrosion resistance, biocompatibility, and other aspects compared to other titanium alloy powders. In addition, due to its mature manufacturing process and wide application background, the availability and cost-effectiveness of Ti6Al4V powder in the market are relatively high.
