Ni-Cu Clad Plate Nickel Copper Clad Plate nickel plated copper sheet

Overview of Nickel Plated Copper Sheet

Nickel/copper clad plate is a metal composite material, which has the function of cladding layer and the combination of toughness and toughness of the base layer. The base material ensures the toughness and strength of the stainless steel clad plate. Clad materials give stainless steel clad plates more properties, such as corrosion resistance given by stainless steel, nickel, and alloys, titanium and titanium alloys; wear resistance given by wear-resistant steel and martensitic stainless steel.



Advantage Characteristics of Nickel Plated Copper Sheet

Good corrosion resistance: the structure of copper-nickel alloy is a continuous solid solution, which improves its corrosion resistance.
High strength: Nickel-copper composite plate is highly strong and can enhance corrosion resistance in gears of heavy-duty vehicles.
Good conductivity: the nickel-copper composite board has good conductivity and can reach 98%.
Wear resistance: Nickel-copper composite plate can resist wear; it is more wear-resistant than pure copper.
Good processability: Nickel-copper composite panels are easy to process and can be manufactured into products of various shapes and sizes through various processing methods.
Easy to weld: Various welding operations can be performed, which is convenient for the assembly and maintenance of the production line.

 Parameter table of Nickel clad copper sheet

Parameter	Details
Material Composition	Nickel layer + Copper layer (e.g., Ni200/Ni201 + C11000/C12200)
Thickness Ratio	Customizable (e.g., 10% Ni + 90% Cu, or other ratios as required)
Density	~8.9 g/cm³ (varies based on thickness ratio)
Tensile Strength	300 – 500 MPa (depends on bonding quality and material grades)
Yield Strength	200 – 400 MPa (varies based on material grades and thickness ratio)
Elongation	20% – 40% (depends on material grades and bonding quality)
Thermal Conductivity	~90 W/m·K (Nickel) + ~400 W/m·K (Copper)
Electrical Conductivity	~25% IACS (Nickel) + ~100% IACS (Copper)
Corrosion Resistance	Excellent (Nickel layer provides resistance to corrosion and oxidation)
Bonding Strength	≥150 MPa (typical for explosion-bonded or roll-bonded clad sheets)
Operating Temperature	-200°C to 300°C (-328°F to 572°F) (depends on application)
Applications	Electrical connectors, heat exchangers, marine engineering, and corrosion-resistant components.

Applications of Nickel Plated Copper Sheet

Aerospace field: Nickel/copper composite plates are often used to manufacture aircraft fuselage, wing beams, landing gear, and other structural parts with high strength and corrosion resistance.
Petrochemical field: Nickel/copper composite panels are often used to produce reactors, heat exchangers, separators, and other equipment for petrochemical, oil refining, and other fields.
Medical device field: Nickel/copper composite board is often used to make medical devices, such as oxygen generators, lung washing machines, etc., which can improve medical efficiency and quality.
Architectural decoration field: Nickel/copper composite board is often used to produce anti-theft doors, automatic doors, wall switches, and other equipment used in construction, decoration, and other fields.
Transportation field: Nickel/copper composite panels are often used in producing chassis, body, frame, and other components of automobiles, trains, airplanes, and other vehicles, and are used in transportation and other fields.
Food and beverage field: Nickel/copper composite boards are often used to make food and beverage equipment and appliances such as cans and beverages and are used in food, drink, and other fields.



 Applications of Nickel Plated Copper Sheet

Grade of Nickel Plated Copper Sheet

N4.N6.NCu28-2.5-1 5,NCu30.NS312.NS336.NS142

Production Method of Nickel clad copper sheet

Nickel-clad copper sheets are generally generated utilizing surge bonding or roll bonding . In surge bonding, a high-energy surge compels the nickel and copper layers with each other under severe stress, developing a solid metallurgical bond at the user interface. In roll bonding, the steels are warmed and travelled through rollers under high stress to attain bonding. Both techniques call for *surface area prep work (cleansing and degreasing) to guarantee ideal attachment. Post-bonding, the sheets might undertake ** warm therapy ** to boost bond toughness and mechanical residential properties. These approaches make sure superb bonding high quality, electric conductivity, and deterioration resistance for commercial applications.

Company Profile

RBOSCHCO is a trusted global chemical material supplier & manufacturer with over 12-year-experience in providing super high-quality chemicals and nanomaterials, including boride powder, nitride powder, graphite powder, sulfide powder, 3D printing powder, etc.The company has a professional technical department and Quality Supervision Department, a well-equipped laboratory, and equipped with advanced testing equipment and after-sales customer service center.If you are looking for high-quality Nickel Plated Copper Sheet, please feel free to contact us or click on the needed products to send an inquiry.

Storage Condition of  Nickel clad copper sheet

Nickel-clad copper sheets should be stored in a dry, clean, and well-ventilated environment to prevent moisture absorption and corrosion. Ideal storage temperature is between 10°C to 30°C (50°F to 86°F). Avoid exposure to high humidity, direct sunlight, or corrosive substances such as acids, alkalis, or salt spray. Use protective packaging (e.g., VCI film, desiccants, or anti-tarnish paper) to shield the sheets from oxidation and contamination. Store them horizontally on flat racks or pallets to avoid deformation and ensure proper airflow. Regularly inspect for signs of corrosion, especially at the edges or bonding interface. Proper storage ensures the material retains its electrical conductivity, corrosion resistance, and surface quality.

Payment Methods of Nickel Plated Copper Sheet

L/C, T/T, Western Union, Paypal, Credit Card etc.

Packing of Nickel Plated Copper Sheet

We have many different kinds of packing which depend on the quantity.

Shipment of Nickel Plated Copper Sheet

By sea, by air, by express as soon as possible once payment receipt

Standard of Nickel Plated Copper Sheet

NB.T 47002.2-2009

SA-265



5 FAQs of Nickel clad copper sheet

Q1

What is the bonding strength of nickel-copper composite steel plates?

Answer: The bonding strength of nickel-copper composite steel plates depends on the production process and the quality of the composite interface. Through reasonable process control and interface treatment, higher bonding strength can be obtained.

Q2

What is the corrosion resistance of nickel-copper composite steel plates?

Answer: The nickel layer in the nickel-copper composite steel plate has good corrosion resistance and can resist erosion by a variety of corrosive media. The copper layer provides good electrical and thermal conductivity.

Q3

How to surface treat nickel-copper composite steel plate?

Answer: The surface treatment of nickel-copper composite steel plate can be polished, sandblasted, electroplated and other treatments as needed to improve its appearance and performance.

Q4

How does the price of nickel-copper composite steel plate compare with ordinary steel plate?

Answer: Because nickel-copper composite steel plates use high-cost nickel and copper materials, their prices are usually higher than ordinary steel plates.

Q5

Is nickel-copper composite steel plate easy to process and form?

Answer: Nickel-copper composite steel plates are challenging to process and form, requiring appropriate processes and tools. However, through reasonable process control, good processing and forming effects can still be achieved.
