Aluminum Clad Copper Plate Aluminum Copper Clad Plate

Overview of Aluminum Copper Clad Plate

The aluminum copper clad plate is a clad material composed of an aluminum alloy plate and a copper plate, and its structure is composed of an aluminum alloy plate and a copper plate. Aluminum copper clad plates have the advantages of light weight, corrosion resistance, high strength, high temperature resistance, wear resistance, fatigue resistance, and good self-lubrication performance. They are widely used in construction, aviation, transportation, electronics, medical and other fields.

 Features of Aluminum Copper Clad Plate

The main features of aluminum copper clad plates are as follows: Light weight: The weight of the aluminum/copper clad plate is only about 1/3 of the traditional pure aluminum plate, so it can significantly reduce the load of the building and reduce the structural cost. Corrosion resistance: The surface of the aluminum copper-clad plate has good corrosion resistance, which can effectively prevent the erosion of buildings by corrosive gases such as acid rain and salt spray.High strength: Aluminum copper-clad plates have very high strength and can be made into various structural parts or parts with complex shapes, uneven thickness, and large loads.High-temperature resistance: Aluminum copper-clad plates can withstand high temperatures up to 1000°C, so they are instrumental in many high-temperature applications.Wear resistance: The wear resistance of aluminum copper-clad plates is perfect; it can effectively reduce friction, reduce wear and tear, and prolong the service life of buildings.Conductivity: Aluminum conducts electricity even better than copper.Recycling: Aluminum is 100% recyclable without losing any of its natural properties.

Parameter table of Aluminum Copper Clad Plate

Parameter	Details
Material Composition	Aluminum layer + Copper layer (e.g., Al 1050/6061 + C11000/C12200)
Thickness Ratio	Customizable (e.g., 10% Al + 90% Cu, or other ratios as required)
Density	~2.7 – 8.9 g/cm³ (varies based on thickness ratio)
Tensile Strength	200 – 400 MPa (depends on bonding quality and material grades)
Yield Strength	150 – 350 MPa (varies based on material grades and thickness ratio)
Elongation	10% – 25% (depends on material grades and bonding quality)
Thermal Conductivity	~200 W/m·K (Aluminum) + ~400 W/m·K (Copper)
Electrical Conductivity	~60% IACS (Aluminum) + ~100% IACS (Copper)
Corrosion Resistance	Good (Aluminum layer provides resistance to corrosion)
Bonding Strength	≥150 MPa (typical for explosion-bonded or roll-bonded clad plates)
Operating Temperature	-200°C to 300°C (-328°F to 572°F) (depends on application)
Applications	Heat exchangers, electrical connectors, automotive components, and lightweight structural applications.

Application of Aluminum Copper Clad Plate

The application fields of aluminum copper-clad plates include construction, aviation, transportation, electronics, medical treatment, and other fields. Specific applications include but are not limited to:Construction: Aluminum copper-clad plates can be used for building exterior walls, interior partitions, stair railings, door, and window frames, etc., due to their lightweight, corrosion resistance, high strength, high-temperature resistance, wear resistance, fatigue resistance, and good self-lubricating properties and other advantages, can improve the safety, comfort, and durability of buildings. Transportation: Aluminum copper-clad plates can be used to manufacture automobile bodies, railway carriages, ship decks, rolling stock, aviation equipment, etc. Due to their lightweight, high strength, and corrosion resistance, they can improve load-carrying capacity and safety. Electronics: aluminum copper boards can be used to manufacture electronic product casings. Medical aspects: Aluminum copper-clad plates can be used to manufacture medical device shells, such as medical beds, medical carts, operating tables, etc. Due to their lightweight, high strength, and corrosion resistance, they can improve service life and safety.

 Applications of Aluminum Copper Clad Plate

Production Method of Aluminum Copper Clad Plate

Aluminum-copper-clad plates are typically produced using explosion bonding or roll bonding. In explosion bonding, a high-energy explosion forces the aluminum and copper layers together under extreme pressure, creating a strong metallurgical bond at the interface. In roll bonding, the metals are heated and passed through rollers under high pressure to achieve bonding. Both techniques require surface preparation (cleansing and degreasing) to ensure an optimum bond. Post-bonding, home plates may undertake heat treatment to boost bond strength and mechanical buildings. These approaches ensure exceptional bonding top quality, thermal and electric conductivity, and lightweight characteristics for industrial applications.



Company Profile

RBOSCHCO is a trusted global chemical material supplier & manufacturer with over 12-year-experience in providing super high-quality chemicals and nanomaterials, including boride powder, nitride powder, graphite powder, sulfide powder, 3D printing powder, etc.The company has a professional technical department and Quality Supervision Department, a well-equipped laboratory, and equipped with advanced testing equipment and after-sales customer service center.If you are looking for high-quality Aluminum Copper Clad Plate, please feel free to contact us or click on the needed products to send an inquiry.

Storage Condition of Aluminum Copper Clad Plate

Aluminum-copper-clad plates should be stored in a dry, clean, and well-ventilated environment to prevent moisture absorption and corrosion. Ideal storage temperature is between 10°C to 30°C (50°F to 86°F). Avoid exposure to high humidity, direct sunlight, or corrosive substances such as acids, alkalis, or salt spray. Use protective packaging (e.g., VCI film or desiccants) to shield the plates from oxidation and contamination. Store them horizontally on flat racks or pallets to avoid deformation and ensure proper airflow. Regularly inspect for signs of corrosion, especially at the edges or bonding interface. Proper storage ensures the material retains its structural integrity, thermal/electrical conductivity, and performance.

Packing of Aluminum Copper Clad Plate

We have many different kinds of packing which depend on the quantity.

Payment Methods of Aluminum Copper Clad Plate

L/C, T/T, Western Union, Paypal, Credit Card etc.

Shipment of Aluminum Copper Clad Plate

By sea, by air, by express as soon as possible once payment receipt

5 FAQs of Aluminum Copper Clad Plate

Q1

What is the manufacturing process of aluminum copper clad laminate?

Answer: The manufacturing process of aluminum copper-clad laminate mainly includes steps such as pretreatment, compounding, rolling and heat treatment. Pretreatment includes cleaning and surface treatment. Composite is to combine aluminum and copper through rolling, explosion welding or hot pressing. Rolling makes the composite plate reach the required thickness and size. Heat treatment can improve the material quality. performance.

Q2

What are the advantages of aluminum copper clad laminates compared to other conductive materials?

Answer: Aluminum copper-clad laminate combines the advantages of aluminum and copper and has the advantages of light weight, good conductivity, corrosion resistance, and easy processing. In addition, its unique composite structure improves the overall performance and stability of the material.

Q3

What is the electrical conductivity of aluminum copper clad laminate?

Answer: Aluminum copper-clad laminate has good electrical conductivity and can meet various electrical connection and electromagnetic shielding requirements. Its copper layer provides an excellent conductive channel, allowing current to flow smoothly.

Q4

What is the thermal conductivity of aluminum copper clad laminate

Answer: Aluminum copper-clad laminate also has good thermal conductivity and can effectively dissipate heat. This material has a wide range of applications in heat sinks, heat exchangers and other fields, and can improve the stability and reliability of equipment.

Q5

What is the processing performance of aluminum copper clad laminate?

Answer: Aluminum copper-clad laminate has good processing performance and can be used for cutting, bending, welding and other processing operations. Its surface is flat and smooth, making it easy to carry out subsequent processing, such as spraying, electroplating, etc.
